Constant OBSS PD algorithm. More...
#include "constant-obss-pd-algorithm.h"
Public Member Functions | |
ConstantObssPdAlgorithm () | |
void | ConnectWifiNetDevice (const Ptr< WifiNetDevice > device) override |
Connect the WifiNetDevice and setup eventual callbacks. More... | |
void | ReceiveHeSigA (HeSigAParameters params) override |
Public Member Functions inherited from ns3::ObssPdAlgorithm | |
double | GetObssPdLevel () const |
void | ResetPhy (HeSigAParameters params) |
Reset PHY to IDLE. More... | |
void | SetObssPdLevel (double level) |
Public Member Functions inherited from ns3::Object | |
Object () | |
Constructor. More... | |
~Object () override | |
Destructor. More... | |
void | AggregateObject (Ptr< Object > other) |
Aggregate two Objects together. More... | |
void | Dispose () |
Dispose of this Object. More... | |
AggregateIterator | GetAggregateIterator () const |
Get an iterator to the Objects aggregated to this one. More... | |
TypeId | GetInstanceTypeId () const override |
Get the most derived TypeId for this Object. More... | |
template<typename T > | |
Ptr< T > | GetObject () const |
Get a pointer to the requested aggregated Object. More... | |
template<> | |
Ptr< Object > | GetObject () const |
Specialization of () for objects of type ns3::Object. More... | |
template<typename T > | |
Ptr< T > | GetObject (TypeId tid) const |
Get a pointer to the requested aggregated Object by TypeId. More... | |
template<> | |
Ptr< Object > | GetObject (TypeId tid) const |
Specialization of (TypeId tid) for objects of type ns3::Object. More... | |
void | Initialize () |
Invoke DoInitialize on all Objects aggregated to this one. More... | |
bool | IsInitialized () const |
Check if the object has been initialized. More... | |
Public Member Functions inherited from ns3::SimpleRefCount< Object, ObjectBase, ObjectDeleter > | |
SimpleRefCount () | |
Default constructor. More... | |
SimpleRefCount (const SimpleRefCount &o[[maybe_unused]]) | |
Copy constructor. More... | |
uint32_t | GetReferenceCount () const |
Get the reference count of the object. More... | |
SimpleRefCount & | operator= (const SimpleRefCount &o[[maybe_unused]]) |
Assignment operator. More... | |
void | Ref () const |
Increment the reference count. More... | |
void | Unref () const |
Decrement the reference count. More... | |
Public Member Functions inherited from ns3::ObjectBase | |
virtual | ~ObjectBase () |
Virtual destructor. More... | |
void | GetAttribute (std::string name, AttributeValue &value) const |
Get the value of an attribute, raising fatal errors if unsuccessful. More... | |
bool | GetAttributeFailSafe (std::string name, AttributeValue &value) const |
Get the value of an attribute without raising errors. More... | |
void | SetAttribute (std::string name, const AttributeValue &value) |
Set a single attribute, raising fatal errors if unsuccessful. More... | |
bool | SetAttributeFailSafe (std::string name, const AttributeValue &value) |
Set a single attribute without raising errors. More... | |
bool | TraceConnect (std::string name, std::string context, const CallbackBase &cb) |
Connect a TraceSource to a Callback with a context. More... | |
bool | TraceConnectWithoutContext (std::string name, const CallbackBase &cb) |
Connect a TraceSource to a Callback without a context. More... | |
bool | TraceDisconnect (std::string name, std::string context, const CallbackBase &cb) |
Disconnect from a TraceSource a Callback previously connected with a context. More... | |
bool | TraceDisconnectWithoutContext (std::string name, const CallbackBase &cb) |
Disconnect from a TraceSource a Callback previously connected without a context. More... | |
Static Public Member Functions | |
static TypeId | GetTypeId () |
Get the type ID. More... | |
Static Public Member Functions inherited from ns3::ObssPdAlgorithm | |
static TypeId | GetTypeId () |
Get the type ID. More... | |
Static Public Member Functions inherited from ns3::Object | |
static TypeId | GetTypeId () |
Register this type. More... | |
Static Public Member Functions inherited from ns3::ObjectBase | |
static TypeId | GetTypeId () |
Get the type ID. More... | |
Additional Inherited Members | |
Public Types inherited from ns3::ObssPdAlgorithm | |
typedef void(* | ResetTracedCallback) (uint8_t bssColor, double rssiDbm, bool powerRestricted, double txPowerMaxDbmSiso, double txPowerMaxDbmMimo) |
TracedCallback signature for OBSS_PD reset events. More... | |
Protected Member Functions inherited from ns3::ObssPdAlgorithm | |
void | DoDispose () override |
Destructor implementation. More... | |
Protected Member Functions inherited from ns3::Object | |
Object (const Object &o) | |
Copy an Object. More... | |
virtual void | DoInitialize () |
Initialize() implementation. More... | |
virtual void | NotifyNewAggregate () |
Notify all Objects aggregated to this one of a new Object being aggregated. More... | |
Protected Member Functions inherited from ns3::ObjectBase | |
void | ConstructSelf (const AttributeConstructionList &attributes) |
Complete construction of ObjectBase; invoked by derived classes. More... | |
virtual void | NotifyConstructionCompleted () |
Notifier called once the ObjectBase is fully constructed. More... | |
Protected Attributes inherited from ns3::ObssPdAlgorithm | |
Ptr< WifiNetDevice > | m_device |
Pointer to the WifiNetDevice. More... | |
Related Functions inherited from ns3::ObjectBase | |
static TypeId | GetObjectIid () |
Ensure the TypeId for ObjectBase gets fully configured to anchor the inheritance tree properly. More... | |
Constant OBSS PD algorithm.
This constant OBSS_PD algorithm is a simple OBSS_PD algorithm which evaluates if a receiving signal should be accepted or rejected based on a constant threshold.
Once a HE-SIG-A has been received by the PHY, the ReceiveHeSigA method is triggered. The algorithm then checks whether this is an OBSS frame by comparing its own BSS color with the BSS color of the received preamble. If this is an OBSS frame, it compares the received RSSI with its configured OBSS_PD level value. The PHY then gets reset to IDLE state in case the received RSSI is lower than that constant OBSS PD level value, and is informed about TX power restrictions that might be applied to the next transmission.
Definition at line 42 of file constant-obss-pd-algorithm.h.
ns3::ConstantObssPdAlgorithm::ConstantObssPdAlgorithm | ( | ) |
Definition at line 40 of file constant-obss-pd-algorithm.cc.
References NS_LOG_FUNCTION.
|
overridevirtual |
Connect the WifiNetDevice and setup eventual callbacks.
device | the WifiNetDevice |
Reimplemented from ns3::ObssPdAlgorithm.
Definition at line 57 of file constant-obss-pd-algorithm.cc.
References ns3::ObssPdAlgorithm::ConnectWifiNetDevice(), ns3::WifiNetDevice::GetPhy(), ns3::WifiPhy::GetPhyEntity(), ns3::MakeCallback(), NS_ASSERT, third::phy, ReceiveHeSigA(), ns3::WIFI_MOD_CLASS_EHT, ns3::WIFI_MOD_CLASS_HE, and ns3::WIFI_STANDARD_80211be.
|
static |
Get the type ID.
Definition at line 47 of file constant-obss-pd-algorithm.cc.
References ns3::TypeId::SetParent().
|
overridevirtual |
params | the HE-SIG-A parameters |
Evaluate the receipt of HE-SIG-A.
Implements ns3::ObssPdAlgorithm.
Definition at line 73 of file constant-obss-pd-algorithm.cc.
References ns3::WifiNetDevice::GetHeConfiguration(), ns3::WifiNetDevice::GetMac(), ns3::Object::GetObject(), ns3::ObssPdAlgorithm::GetObssPdLevel(), ns3::ObssPdAlgorithm::m_device, third::mac, NS_ASSERT, NS_LOG_DEBUG, NS_LOG_FUNCTION, two-ray-to-three-gpp-ch-calibration::params, ns3::ObssPdAlgorithm::ResetPhy(), and ns3::WToDbm().
Referenced by ConnectWifiNetDevice().
