ICMPv6 redirected option. More...
#include "icmpv6-header.h"
Inheritance diagram for ns3::Icmpv6OptionRedirected: Collaboration diagram for ns3::Icmpv6OptionRedirected:Public Member Functions | |
| Icmpv6OptionRedirected () | |
| Constructor. More... | |
| ~Icmpv6OptionRedirected () override | |
| Destructor. More... | |
| uint32_t | Deserialize (Buffer::Iterator start) override |
| Deserialize the packet. More... | |
| TypeId | GetInstanceTypeId () const override |
| Get the instance type ID. More... | |
| uint32_t | GetSerializedSize () const override |
| Get the serialized size. More... | |
| void | Print (std::ostream &os) const override |
| Print information. More... | |
| void | Serialize (Buffer::Iterator start) const override |
| Serialize the packet. More... | |
| void | SetPacket (Ptr< Packet > packet) |
| Set the redirected packet. More... | |
| Public Member Functions inherited from ns3::Icmpv6OptionHeader | |
| Icmpv6OptionHeader () | |
| Constructor. More... | |
| ~Icmpv6OptionHeader () override | |
| Destructor. More... | |
| uint8_t | GetLength () const |
| Get the length of the option in 8 bytes unit. More... | |
| uint8_t | GetType () const |
| Get the type of the option. More... | |
| void | SetLength (uint8_t len) |
| Set the length of the option. More... | |
| void | SetType (uint8_t type) |
| Set the type of the option. More... | |
| Public Member Functions inherited from ns3::Header | |
| ~Header () override | |
| virtual uint32_t | Deserialize (Buffer::Iterator start)=0 |
| Deserialize the object from a buffer iterator. More... | |
| virtual uint32_t | Deserialize (Buffer::Iterator start, Buffer::Iterator end) |
| Deserialize the object from a buffer iterator. More... | |
| Public Member Functions inherited from ns3::Chunk | |
| virtual uint32_t | Deserialize (Buffer::Iterator start, Buffer::Iterator end) |
| Deserialize the object from a buffer iterator. More... | |
| Public Member Functions inherited from ns3::ObjectBase | |
| virtual | ~ObjectBase () |
| Virtual destructor. More... | |
| void | GetAttribute (std::string name, AttributeValue &value) const |
| Get the value of an attribute, raising fatal errors if unsuccessful. More... | |
| bool | GetAttributeFailSafe (std::string name, AttributeValue &value) const |
| Get the value of an attribute without raising errors. More... | |
| void | SetAttribute (std::string name, const AttributeValue &value) |
| Set a single attribute, raising fatal errors if unsuccessful. More... | |
| bool | SetAttributeFailSafe (std::string name, const AttributeValue &value) |
| Set a single attribute without raising errors. More... | |
| bool | TraceConnect (std::string name, std::string context, const CallbackBase &cb) |
| Connect a TraceSource to a Callback with a context. More... | |
| bool | TraceConnectWithoutContext (std::string name, const CallbackBase &cb) |
| Connect a TraceSource to a Callback without a context. More... | |
| bool | TraceDisconnect (std::string name, std::string context, const CallbackBase &cb) |
| Disconnect from a TraceSource a Callback previously connected with a context. More... | |
| bool | TraceDisconnectWithoutContext (std::string name, const CallbackBase &cb) |
| Disconnect from a TraceSource a Callback previously connected without a context. More... | |
Static Public Member Functions | |
| static TypeId | GetTypeId () |
| Get the UID of this class. More... | |
| Static Public Member Functions inherited from ns3::Icmpv6OptionHeader | |
| static TypeId | GetTypeId () |
| Get the UID of this class. More... | |
| Static Public Member Functions inherited from ns3::Header | |
| static TypeId | GetTypeId () |
| Get the type ID. More... | |
| Static Public Member Functions inherited from ns3::Chunk | |
| static TypeId | GetTypeId () |
| Get the type ID. More... | |
| Static Public Member Functions inherited from ns3::ObjectBase | |
| static TypeId | GetTypeId () |
| Get the type ID. More... | |
Private Attributes | |
| Ptr< Packet > | m_packet |
| The redirected packet. More... | |
Additional Inherited Members | |
| Protected Member Functions inherited from ns3::ObjectBase | |
| void | ConstructSelf (const AttributeConstructionList &attributes) |
| Complete construction of ObjectBase; invoked by derived classes. More... | |
| virtual void | NotifyConstructionCompleted () |
| Notifier called once the ObjectBase is fully constructed. More... | |
| Related Functions inherited from ns3::ObjectBase | |
| static TypeId | GetObjectIid () |
| Ensure the TypeId for ObjectBase gets fully configured to anchor the inheritance tree properly. More... | |
ICMPv6 redirected option.
Definition at line 1692 of file icmpv6-header.h.
| ns3::Icmpv6OptionRedirected::Icmpv6OptionRedirected | ( | ) |
Constructor.
Definition at line 2082 of file icmpv6-header.cc.
References ns3::Icmpv6Header::ICMPV6_OPT_REDIRECTED, NS_LOG_FUNCTION, and ns3::Icmpv6OptionHeader::SetType().
Here is the call graph for this function:
|
override |
Destructor.
Definition at line 2089 of file icmpv6-header.cc.
References m_packet, and NS_LOG_FUNCTION.
|
overridevirtual |
Deserialize the packet.
| start | start offset |
Reimplemented from ns3::Icmpv6OptionHeader.
Definition at line 2138 of file icmpv6-header.cc.
References ns3::Icmpv6OptionHeader::GetLength(), GetSerializedSize(), m_packet, NS_LOG_FUNCTION, ns3::Buffer::Iterator::Read(), ns3::Buffer::Iterator::ReadU16(), ns3::Buffer::Iterator::ReadU32(), ns3::Buffer::Iterator::ReadU8(), ns3::Icmpv6OptionHeader::SetLength(), ns3::Icmpv6OptionHeader::SetType(), and two-ray-to-three-gpp-ch-calibration::start.
Here is the call graph for this function:
|
overridevirtual |
Get the instance type ID.
Reimplemented from ns3::Icmpv6OptionHeader.
Definition at line 2076 of file icmpv6-header.cc.
References GetTypeId(), and NS_LOG_FUNCTION.
Here is the call graph for this function:
|
overridevirtual |
Get the serialized size.
Reimplemented from ns3::Icmpv6OptionHeader.
Definition at line 2112 of file icmpv6-header.cc.
References ns3::Packet::GetSize(), m_packet, and NS_LOG_FUNCTION.
Referenced by Deserialize().
Here is the call graph for this function: Here is the caller graph for this function:
|
static |
Get the UID of this class.
Definition at line 2066 of file icmpv6-header.cc.
References ns3::TypeId::SetParent().
Referenced by GetInstanceTypeId().
Here is the call graph for this function: Here is the caller graph for this function:
|
overridevirtual |
Print information.
| os | output stream |
Reimplemented from ns3::Icmpv6OptionHeader.
Definition at line 2105 of file icmpv6-header.cc.
References ns3::Icmpv6OptionHeader::GetLength(), ns3::Icmpv6OptionHeader::GetType(), and NS_LOG_FUNCTION.
Here is the call graph for this function:
|
overridevirtual |
Serialize the packet.
| start | start offset |
Reimplemented from ns3::Icmpv6OptionHeader.
Definition at line 2119 of file icmpv6-header.cc.
References ns3::Packet::CopyData(), ns3::Icmpv6OptionHeader::GetLength(), ns3::Packet::GetSize(), ns3::Icmpv6OptionHeader::GetType(), m_packet, NS_LOG_FUNCTION, two-ray-to-three-gpp-ch-calibration::start, ns3::Buffer::Iterator::Write(), ns3::Buffer::Iterator::WriteU16(), ns3::Buffer::Iterator::WriteU32(), and ns3::Buffer::Iterator::WriteU8().
Here is the call graph for this function:Set the redirected packet.
| packet | the redirected packet |
Definition at line 2096 of file icmpv6-header.cc.
References ns3::Packet::Copy(), ns3::Packet::GetSize(), m_packet, NS_ASSERT, NS_LOG_FUNCTION, and ns3::Icmpv6OptionHeader::SetLength().
Referenced by ns3::Icmpv6L4Protocol::SendRedirection().
Here is the call graph for this function: Here is the caller graph for this function:The redirected packet.
Definition at line 1752 of file icmpv6-header.h.
Referenced by ~Icmpv6OptionRedirected(), Deserialize(), GetSerializedSize(), Serialize(), and SetPacket().
