Defines a single carrier for enb, and contains pointers to LteEnbPhy, LteEnbMac, LteFfrAlgorithm, and FfMacScheduler objects. More...
#include "component-carrier-enb.h"
Public Member Functions | |
ComponentCarrierEnb () | |
~ComponentCarrierEnb () override | |
void | DoDispose () override |
Destructor implementation. More... | |
Ptr< FfMacScheduler > | GetFfMacScheduler () |
Ptr< LteFfrAlgorithm > | GetFfrAlgorithm () |
Ptr< LteEnbMac > | GetMac () |
Ptr< LteEnbPhy > | GetPhy () |
void | SetFfMacScheduler (Ptr< FfMacScheduler > s) |
Set the FfMacScheduler Algorithm. More... | |
void | SetFfrAlgorithm (Ptr< LteFfrAlgorithm > s) |
Set the LteFfrAlgorithm. More... | |
void | SetMac (Ptr< LteEnbMac > s) |
Set the LteEnbMac. More... | |
void | SetPhy (Ptr< LteEnbPhy > s) |
Set the LteEnbPhy. More... | |
Public Member Functions inherited from ns3::ComponentCarrierBaseStation | |
ComponentCarrierBaseStation () | |
Constructor. More... | |
~ComponentCarrierBaseStation () override | |
~ComponentCarrierBaseStation More... | |
uint16_t | GetCellId () const |
Get cell identifier. More... | |
void | SetCellId (uint16_t cellId) |
Set physical cell identifier. More... | |
Public Member Functions inherited from ns3::ComponentCarrier | |
ComponentCarrier () | |
~ComponentCarrier () override | |
void | DoDispose () override |
Destructor implementation. More... | |
uint32_t | GetCsgId () const |
Returns the CSG ID of the eNodeB. More... | |
bool | GetCsgIndication () const |
Returns the CSG indication flag of the eNodeB. More... | |
uint16_t | GetDlBandwidth () const |
uint32_t | GetDlEarfcn () const |
uint16_t | GetUlBandwidth () const |
uint32_t | GetUlEarfcn () const |
bool | IsPrimary () const |
Checks if the carrier is the primary carrier. More... | |
void | SetAsPrimary (bool primaryCarrier) |
Set as primary carrier. More... | |
void | SetCsgId (uint32_t csgId) |
Associate the eNodeB device with a particular CSG. More... | |
void | SetCsgIndication (bool csgIndication) |
Enable or disable the CSG indication flag. More... | |
virtual void | SetDlBandwidth (uint16_t bw) |
void | SetDlEarfcn (uint32_t earfcn) |
virtual void | SetUlBandwidth (uint16_t bw) |
void | SetUlEarfcn (uint32_t earfcn) |
Public Member Functions inherited from ns3::Object | |
Object () | |
Constructor. More... | |
~Object () override | |
Destructor. More... | |
void | AggregateObject (Ptr< Object > other) |
Aggregate two Objects together. More... | |
void | Dispose () |
Dispose of this Object. More... | |
AggregateIterator | GetAggregateIterator () const |
Get an iterator to the Objects aggregated to this one. More... | |
TypeId | GetInstanceTypeId () const override |
Get the most derived TypeId for this Object. More... | |
template<typename T > | |
Ptr< T > | GetObject () const |
Get a pointer to the requested aggregated Object. More... | |
template<> | |
Ptr< Object > | GetObject () const |
Specialization of () for objects of type ns3::Object. More... | |
template<typename T > | |
Ptr< T > | GetObject (TypeId tid) const |
Get a pointer to the requested aggregated Object by TypeId. More... | |
template<> | |
Ptr< Object > | GetObject (TypeId tid) const |
Specialization of (TypeId tid) for objects of type ns3::Object. More... | |
void | Initialize () |
Invoke DoInitialize on all Objects aggregated to this one. More... | |
bool | IsInitialized () const |
Check if the object has been initialized. More... | |
Public Member Functions inherited from ns3::SimpleRefCount< Object, ObjectBase, ObjectDeleter > | |
SimpleRefCount () | |
Default constructor. More... | |
SimpleRefCount (const SimpleRefCount &o[[maybe_unused]]) | |
Copy constructor. More... | |
uint32_t | GetReferenceCount () const |
Get the reference count of the object. More... | |
SimpleRefCount & | operator= (const SimpleRefCount &o[[maybe_unused]]) |
Assignment operator. More... | |
void | Ref () const |
Increment the reference count. More... | |
void | Unref () const |
Decrement the reference count. More... | |
Public Member Functions inherited from ns3::ObjectBase | |
virtual | ~ObjectBase () |
Virtual destructor. More... | |
void | GetAttribute (std::string name, AttributeValue &value) const |
Get the value of an attribute, raising fatal errors if unsuccessful. More... | |
bool | GetAttributeFailSafe (std::string name, AttributeValue &value) const |
Get the value of an attribute without raising errors. More... | |
void | SetAttribute (std::string name, const AttributeValue &value) |
Set a single attribute, raising fatal errors if unsuccessful. More... | |
bool | SetAttributeFailSafe (std::string name, const AttributeValue &value) |
Set a single attribute without raising errors. More... | |
bool | TraceConnect (std::string name, std::string context, const CallbackBase &cb) |
Connect a TraceSource to a Callback with a context. More... | |
bool | TraceConnectWithoutContext (std::string name, const CallbackBase &cb) |
Connect a TraceSource to a Callback without a context. More... | |
bool | TraceDisconnect (std::string name, std::string context, const CallbackBase &cb) |
Disconnect from a TraceSource a Callback previously connected with a context. More... | |
bool | TraceDisconnectWithoutContext (std::string name, const CallbackBase &cb) |
Disconnect from a TraceSource a Callback previously connected without a context. More... | |
Static Public Member Functions | |
static TypeId | GetTypeId () |
Get the type ID. More... | |
Static Public Member Functions inherited from ns3::ComponentCarrierBaseStation | |
static TypeId | GetTypeId () |
Get the type ID. More... | |
Static Public Member Functions inherited from ns3::ComponentCarrier | |
static TypeId | GetTypeId () |
Get the type ID. More... | |
Static Public Member Functions inherited from ns3::Object | |
static TypeId | GetTypeId () |
Register this type. More... | |
Static Public Member Functions inherited from ns3::ObjectBase | |
static TypeId | GetTypeId () |
Get the type ID. More... | |
Protected Member Functions | |
void | DoInitialize () override |
Initialize() implementation. More... | |
Protected Member Functions inherited from ns3::Object | |
Object (const Object &o) | |
Copy an Object. More... | |
virtual void | NotifyNewAggregate () |
Notify all Objects aggregated to this one of a new Object being aggregated. More... | |
Protected Member Functions inherited from ns3::ObjectBase | |
void | ConstructSelf (const AttributeConstructionList &attributes) |
Complete construction of ObjectBase; invoked by derived classes. More... | |
virtual void | NotifyConstructionCompleted () |
Notifier called once the ObjectBase is fully constructed. More... | |
Private Attributes | |
Ptr< LteFfrAlgorithm > | m_ffrAlgorithm |
the FFR algorithm instance of this eNodeB component carrier More... | |
Ptr< LteEnbMac > | m_mac |
the MAC instance of this eNodeB component carrier More... | |
Ptr< LteEnbPhy > | m_phy |
the Phy instance of this eNodeB component carrier More... | |
Ptr< FfMacScheduler > | m_scheduler |
the scheduler instance of this eNodeB component carrier More... | |
Additional Inherited Members | |
Protected Attributes inherited from ns3::ComponentCarrierBaseStation | |
uint16_t | m_cellId {0} |
Cell identifier. More... | |
Protected Attributes inherited from ns3::ComponentCarrier | |
uint32_t | m_csgId {0} |
CSG ID. More... | |
bool | m_csgIndication {false} |
CSG indication. More... | |
uint16_t | m_dlBandwidth {0} |
downlink bandwidth in RBs */ More... | |
uint32_t | m_dlEarfcn {0} |
downlink carrier frequency */ More... | |
bool | m_primaryCarrier {false} |
whether the carrier is primary More... | |
uint16_t | m_ulBandwidth {0} |
uplink bandwidth in RBs */ More... | |
uint32_t | m_ulEarfcn {0} |
uplink carrier frequency */ More... | |
Related Functions inherited from ns3::ObjectBase | |
static TypeId | GetObjectIid () |
Ensure the TypeId for ObjectBase gets fully configured to anchor the inheritance tree properly. More... | |
Defines a single carrier for enb, and contains pointers to LteEnbPhy, LteEnbMac, LteFfrAlgorithm, and FfMacScheduler objects.
Definition at line 45 of file component-carrier-enb.h.
ns3::ComponentCarrierEnb::ComponentCarrierEnb | ( | ) |
Definition at line 69 of file component-carrier-enb.cc.
References NS_LOG_FUNCTION.
|
override |
Definition at line 74 of file component-carrier-enb.cc.
References NS_LOG_FUNCTION.
|
overridevirtual |
Destructor implementation.
This method is called by Dispose() or by the Object's destructor, whichever comes first.
Subclasses are expected to implement their real destruction code in an overridden version of this method and chain up to their parent's implementation once they are done. i.e, for simplicity, the destructor of every subclass should be empty and its content should be moved to the associated DoDispose() method.
It is safe to call GetObject() from within this method.
Reimplemented from ns3::Object.
Definition at line 80 of file component-carrier-enb.cc.
References ns3::Object::DoDispose(), m_ffrAlgorithm, m_mac, m_phy, m_scheduler, and NS_LOG_FUNCTION.
|
overrideprotectedvirtual |
Initialize() implementation.
This method is called only once by Initialize(). If the user calls Initialize() multiple times, DoInitialize() is called only the first time.
Subclasses are expected to override this method and chain up to their parent's implementation once they are done. It is safe to call GetObject() and AggregateObject() from within this method.
Reimplemented from ns3::Object.
Definition at line 108 of file component-carrier-enb.cc.
References m_ffrAlgorithm, m_mac, m_phy, m_scheduler, and NS_LOG_FUNCTION.
Ptr< FfMacScheduler > ns3::ComponentCarrierEnb::GetFfMacScheduler | ( | ) |
Definition at line 160 of file component-carrier-enb.cc.
References m_scheduler, and NS_LOG_FUNCTION.
Ptr< LteFfrAlgorithm > ns3::ComponentCarrierEnb::GetFfrAlgorithm | ( | ) |
Definition at line 146 of file component-carrier-enb.cc.
References m_ffrAlgorithm, and NS_LOG_FUNCTION.
Definition at line 132 of file component-carrier-enb.cc.
References m_mac, and NS_LOG_FUNCTION.
Definition at line 118 of file component-carrier-enb.cc.
References m_phy, and NS_LOG_FUNCTION.
|
static |
Get the type ID.
Definition at line 41 of file component-carrier-enb.cc.
References m_ffrAlgorithm, m_mac, m_phy, m_scheduler, ns3::MakePointerAccessor(), and ns3::TypeId::SetParent().
void ns3::ComponentCarrierEnb::SetFfMacScheduler | ( | Ptr< FfMacScheduler > | s | ) |
Set the FfMacScheduler Algorithm.
s | a pointer to the FfMacScheduler |
Definition at line 167 of file component-carrier-enb.cc.
References m_scheduler, and NS_LOG_FUNCTION.
void ns3::ComponentCarrierEnb::SetFfrAlgorithm | ( | Ptr< LteFfrAlgorithm > | s | ) |
Set the LteFfrAlgorithm.
s | a pointer to the LteFfrAlgorithm |
Definition at line 153 of file component-carrier-enb.cc.
References m_ffrAlgorithm, and NS_LOG_FUNCTION.
Set the LteEnbMac.
s | a pointer to the LteEnbMac |
Definition at line 139 of file component-carrier-enb.cc.
References m_mac, and NS_LOG_FUNCTION.
Set the LteEnbPhy.
s | a pointer to the LteEnbPhy |
Definition at line 125 of file component-carrier-enb.cc.
References m_phy, and NS_LOG_FUNCTION.
|
private |
the FFR algorithm instance of this eNodeB component carrier
Definition at line 110 of file component-carrier-enb.h.
Referenced by DoDispose(), DoInitialize(), GetFfrAlgorithm(), GetTypeId(), and SetFfrAlgorithm().
the MAC instance of this eNodeB component carrier
Definition at line 107 of file component-carrier-enb.h.
Referenced by DoDispose(), DoInitialize(), GetMac(), GetTypeId(), and SetMac().
the Phy instance of this eNodeB component carrier
Definition at line 106 of file component-carrier-enb.h.
Referenced by DoDispose(), DoInitialize(), GetPhy(), GetTypeId(), and SetPhy().
|
private |
the scheduler instance of this eNodeB component carrier
Definition at line 108 of file component-carrier-enb.h.
Referenced by DoDispose(), DoInitialize(), GetFfMacScheduler(), GetTypeId(), and SetFfMacScheduler().
