A Discrete-Event Network Simulator
API
ns3::DataCalculator Class Referenceabstract

Calculates data during a simulation. More...

#include "data-calculator.h"

+ Inheritance diagram for ns3::DataCalculator:
+ Collaboration diagram for ns3::DataCalculator:

Public Member Functions

 DataCalculator ()

virtual ~DataCalculator ()

void Disable ()
 Disables DataCalculator when simulation stops. More...

void Enable ()
 Enables DataCalculator when simulation starts. More...

std::string GetContext () const
 Gets the DataCalculator context. More...

bool GetEnabled () const
 Returns whether the DataCalculator is enabled. More...

std::string GetKey () const
 Gets the DataCalculator key. More...

virtual void Output (DataOutputCallback &callback) const =0
 Outputs data based on the provided callback. More...

void SetContext (const std::string context)
 Sets the DataCalculator context to the provided context. More...

void SetKey (const std::string key)
 Sets the DataCalculator key to the provided key. More...

virtual void Start (const Time &startTime)
 Starts DataCalculator at a given time in the simulation. More...

virtual void Stop (const Time &stopTime)
 Stops DataCalculator at a given time in the simulation. More...

- Public Member Functions inherited from ns3::Object
 Object ()
 Constructor. More...

virtual ~Object ()
 Destructor. More...

void AggregateObject (Ptr< Object > other)
 Aggregate two Objects together. More...

void Dispose (void)
 Dispose of this Object. More...

AggregateIterator GetAggregateIterator (void) const
 Get an iterator to the Objects aggregated to this one. More...

virtual TypeId GetInstanceTypeId (void) const
 Get the most derived TypeId for this Object. More...

template<>
Ptr< ObjectGetObject () const
 Specialization of () for objects of type ns3::Object. More...

template<typename T >
Ptr< T > GetObject (TypeId tid) const
 Get a pointer to the requested aggregated Object by TypeId. More...

template<>
Ptr< ObjectGetObject (TypeId tid) const
 Specialization of (TypeId tid) for objects of type ns3::Object. More...

template<typename T >
Ptr< T > GetObject (void) const
 Get a pointer to the requested aggregated Object. More...

void Initialize (void)
 Invoke DoInitialize on all Objects aggregated to this one. More...

bool IsInitialized (void) const
 Check if the object has been initialized. More...

- Public Member Functions inherited from ns3::SimpleRefCount< Object, ObjectBase, ObjectDeleter >
 SimpleRefCount ()
 Default constructor. More...

 SimpleRefCount (const SimpleRefCount &o[[maybe_unused]])
 Copy constructor. More...

uint32_t GetReferenceCount (void) const
 Get the reference count of the object. More...

SimpleRefCountoperator= ([[maybe_unused]] const SimpleRefCount &o)
 Assignment operator. More...

void Ref (void) const
 Increment the reference count. More...

void Unref (void) const
 Decrement the reference count. More...

- Public Member Functions inherited from ns3::ObjectBase
virtual ~ObjectBase ()
 Virtual destructor. More...

void GetAttribute (std::string name, AttributeValue &value) const
 Get the value of an attribute, raising fatal errors if unsuccessful. More...

bool GetAttributeFailSafe (std::string name, AttributeValue &value) const
 Get the value of an attribute without raising erros. More...

void SetAttribute (std::string name, const AttributeValue &value)
 Set a single attribute, raising fatal errors if unsuccessful. More...

bool SetAttributeFailSafe (std::string name, const AttributeValue &value)
 Set a single attribute without raising errors. More...

bool TraceConnect (std::string name, std::string context, const CallbackBase &cb)
 Connect a TraceSource to a Callback with a context. More...

bool TraceConnectWithoutContext (std::string name, const CallbackBase &cb)
 Connect a TraceSource to a Callback without a context. More...

bool TraceDisconnect (std::string name, std::string context, const CallbackBase &cb)
 Disconnect from a TraceSource a Callback previously connected with a context. More...

bool TraceDisconnectWithoutContext (std::string name, const CallbackBase &cb)
 Disconnect from a TraceSource a Callback previously connected without a context. More...


Static Public Member Functions

static TypeId GetTypeId (void)
 Register this type. More...

- Static Public Member Functions inherited from ns3::Object
static TypeId GetTypeId (void)
 Register this type. More...

- Static Public Member Functions inherited from ns3::ObjectBase
static TypeId GetTypeId (void)
 Get the type ID. More...


Protected Member Functions

virtual void DoDispose (void)
 Destructor implementation. More...

- Protected Member Functions inherited from ns3::Object
 Object (const Object &o)
 Copy an Object. More...

virtual void DoInitialize (void)
 Initialize() implementation. More...

virtual void NotifyNewAggregate (void)
 Notify all Objects aggregated to this one of a new Object being aggregated. More...

- Protected Member Functions inherited from ns3::ObjectBase
void ConstructSelf (const AttributeConstructionList &attributes)
 Complete construction of ObjectBase; invoked by derived classes. More...

virtual void NotifyConstructionCompleted (void)
 Notifier called once the ObjectBase is fully constructed. More...


Protected Attributes

std::string m_context
 Context value. More...

bool m_enabled
 Descendant classes must check & respect m_enabled! More...

std::string m_key
 Key value. More...


Private Attributes

EventId m_startEvent
 Start event. More...

EventId m_stopEvent
 Stop event. More...


Additional Inherited Members

Detailed Description

Calculates data during a simulation.

Definition at line 111 of file data-calculator.h.

Constructor & Destructor Documentation

◆ DataCalculator()

DataCalculator::DataCalculator ( )

Definition at line 35 of file data-calculator.cc.

References NS_LOG_FUNCTION.

◆ ~DataCalculator()

DataCalculator::~DataCalculator ( )
virtual

Definition at line 41 of file data-calculator.cc.

References NS_LOG_FUNCTION.

Member Function Documentation

◆ Disable()

void DataCalculator::Disable ( void  )

Disables DataCalculator when simulation stops.

Definition at line 118 of file data-calculator.cc.

References m_enabled, and NS_LOG_FUNCTION.

Referenced by Stop().

+ Here is the caller graph for this function:

◆ DoDispose()

void DataCalculator::DoDispose ( void  )
protectedvirtual

Destructor implementation.

This method is called by Dispose() or by the Object's destructor, whichever comes first.

Subclasses are expected to implement their real destruction code in an overridden version of this method and chain up to their parent's implementation once they are done. i.e, for simplicity, the destructor of every subclass should be empty and its content should be moved to the associated DoDispose() method.

It is safe to call GetObject() from within this method.

Reimplemented from ns3::Object.

Reimplemented in ns3::TimeMinMaxAvgTotalCalculator, ns3::CounterCalculator< T >, ns3::CounterCalculator< uint32_t >, ns3::MinMaxAvgTotalCalculator< T >, ns3::MinMaxAvgTotalCalculator< uint32_t >, ns3::MinMaxAvgTotalCalculator< double >, ns3::MinMaxAvgTotalCalculator< uint64_t >, ns3::PacketSizeMinMaxAvgTotalCalculator, and ns3::PacketCounterCalculator.

Definition at line 59 of file data-calculator.cc.

References ns3::Simulator::Cancel(), ns3::Object::DoDispose(), m_startEvent, m_stopEvent, and NS_LOG_FUNCTION.

Referenced by ns3::MinMaxAvgTotalCalculator< T >::DoDispose(), ns3::CounterCalculator< T >::DoDispose(), and ns3::TimeMinMaxAvgTotalCalculator::DoDispose().

+ Here is the call graph for this function:
+ Here is the caller graph for this function:

◆ Enable()

void DataCalculator::Enable ( void  )

Enables DataCalculator when simulation starts.

Definition at line 109 of file data-calculator.cc.

References m_enabled, and NS_LOG_FUNCTION.

Referenced by Start().

+ Here is the caller graph for this function:

◆ GetContext()

std::string DataCalculator::GetContext ( void  ) const

Gets the DataCalculator context.

Returns
Context value as a string

Definition at line 100 of file data-calculator.cc.

References m_context, and NS_LOG_FUNCTION.

◆ GetEnabled()

bool DataCalculator::GetEnabled ( ) const

Returns whether the DataCalculator is enabled.

Returns
true if DataCalculator is enabled

Definition at line 127 of file data-calculator.cc.

References m_enabled, and NS_LOG_FUNCTION.

◆ GetKey()

std::string DataCalculator::GetKey ( void  ) const

Gets the DataCalculator key.

Returns
Key value as a string

Definition at line 81 of file data-calculator.cc.

References m_key, and NS_LOG_FUNCTION.

◆ GetTypeId()

TypeId DataCalculator::GetTypeId ( void  )
static

Register this type.

Returns
The TypeId.

Definition at line 48 of file data-calculator.cc.

References ns3::TypeId::SetParent().

+ Here is the call graph for this function:

◆ Output()

◆ SetContext()

void DataCalculator::SetContext ( const std::string  context)

Sets the DataCalculator context to the provided context.

Parameters
contextContext value as a string

Definition at line 91 of file data-calculator.cc.

References m_context, and NS_LOG_FUNCTION.

◆ SetKey()

void DataCalculator::SetKey ( const std::string  key)

Sets the DataCalculator key to the provided key.

Parameters
keyKey value as a string

Definition at line 72 of file data-calculator.cc.

References m_key, and NS_LOG_FUNCTION.

◆ Start()

void DataCalculator::Start ( const Time startTime)
virtual

Starts DataCalculator at a given time in the simulation.

Parameters
startTime

Definition at line 137 of file data-calculator.cc.

References Enable(), m_startEvent, NS_LOG_FUNCTION, ns3::Simulator::Schedule(), and startTime.

+ Here is the call graph for this function:

◆ Stop()

void DataCalculator::Stop ( const Time stopTime)
virtual

Stops DataCalculator at a given time in the simulation.

Parameters
stopTime

Definition at line 148 of file data-calculator.cc.

References Disable(), m_stopEvent, NS_LOG_FUNCTION, ns3::Simulator::Schedule(), and stopTime.

+ Here is the call graph for this function:

Member Data Documentation

◆ m_context

std::string ns3::DataCalculator::m_context
protected

Context value.

Definition at line 178 of file data-calculator.h.

Referenced by GetContext(), ns3::TimeMinMaxAvgTotalCalculator::Output(), and SetContext().

◆ m_enabled

bool ns3::DataCalculator::m_enabled
protected

Descendant classes must check & respect m_enabled!

Definition at line 175 of file data-calculator.h.

Referenced by Disable(), Enable(), GetEnabled(), and ns3::TimeMinMaxAvgTotalCalculator::Update().

◆ m_key

std::string ns3::DataCalculator::m_key
protected

Key value.

Definition at line 177 of file data-calculator.h.

Referenced by GetKey(), ns3::TimeMinMaxAvgTotalCalculator::Output(), and SetKey().

◆ m_startEvent

EventId ns3::DataCalculator::m_startEvent
private

Start event.

Definition at line 183 of file data-calculator.h.

Referenced by DoDispose(), and Start().

◆ m_stopEvent

EventId ns3::DataCalculator::m_stopEvent
private

Stop event.

Definition at line 184 of file data-calculator.h.

Referenced by DoDispose(), and Stop().


The documentation for this class was generated from the following files:
