ObjectVector Attribute

AttributeValue implementation for ObjectVector. More...

Collaboration diagram for ObjectVector Attribute:

Files
file	object-vector.h
	ns3::ObjectVectorValue attribute value declarations and template implementations.

Classes
class	ObjectVectorChecker
	AttributeChecker implementation for ObjectVectorValue. More...

Typedefs
typedef ObjectPtrContainerValue	ns3::ObjectVectorValue
	ObjectVectorValue is an alias for ObjectPtrContainerValue. More...

Functions
template<typename T , typename U , typename INDEX >
Ptr< const AttributeAccessor >	ns3::MakeObjectVectorAccessor (INDEX(T::*getN)(void) const, Ptr< U >(T::*get)(INDEX) const)
	Create an AttributeAccessor using a container class indexed get method. More...
template<typename T , typename U , typename INDEX >
Ptr< const AttributeAccessor >	ns3::MakeObjectVectorAccessor (Ptr< U >(T::*get)(INDEX) const, INDEX(T::*getN)(void) const)
	Create an AttributeAccessor using a container class indexed get method. More...
template<typename T , typename U >
Ptr< const AttributeAccessor >	ns3::MakeObjectVectorAccessor (U T::*memberVariable)
	MakeAccessorHelper implementation for ObjectVector. More...
template<typename T >
Ptr< const AttributeChecker >	ns3::MakeObjectVectorChecker (void)

Detailed Description

AttributeValue implementation for ObjectVector.

Typedef Documentation

ObjectVectorValue

typedef ObjectPtrContainerValue ns3::ObjectVectorValue

ObjectVectorValue is an alias for ObjectPtrContainerValue.

Definition at line 40 of file object-vector.h.

Function Documentation

MakeObjectVectorAccessor() [1/3]

template<typename T , typename U , typename INDEX >

Ptr< const AttributeAccessor > ns3::MakeObjectVectorAccessor	(	INDEX(T::*)(void) const	getN,
		Ptr< U >(T::*)(INDEX) const	get
	)

Create an AttributeAccessor using a container class indexed get method.

The two versions of this function differ only in argument order.

Template Parameters

T	[deduced] The container class type.
U	[deduced] The type of object the get method returns.
INDEX	[deduced] The type of the index variable.

Parameters

[in]	get	The class method to get a specific instance from the container.
[in]	getN	The class method to return the number of objects in the container.

Returns

The AttributeAccessor.

Definition at line 136 of file object-vector.h.

References nlohmann::detail::get().

Here is the call graph for this function:

MakeObjectVectorAccessor() [2/3]

template<typename T , typename U , typename INDEX >

Ptr< const AttributeAccessor > ns3::MakeObjectVectorAccessor	(	Ptr< U >(T::*)(INDEX) const	get,
		INDEX(T::*)(void) const	getN
	)

Create an AttributeAccessor using a container class indexed get method.

The two versions of this function differ only in argument order.

Template Parameters

T	[deduced] The container class type.
U	[deduced] The type of object the get method returns.
INDEX	[deduced] The type of the index variable.

Parameters

[in]	get	The class method to get a specific instance from the container.
[in]	getN	The class method to return the number of objects in the container.

Returns

The AttributeAccessor.

Definition at line 128 of file object-vector.h.

References nlohmann::detail::get().

Here is the call graph for this function:

MakeObjectVectorAccessor() [3/3]

template<typename T , typename U >

Ptr< const AttributeAccessor > ns3::MakeObjectVectorAccessor

(

U T::*

memberVariable

)

MakeAccessorHelper implementation for ObjectVector.

Template Parameters

V	[explicit] The specific AttributeValue type to use to represent the Attribute.
T	[deduced] The class holding the data member.
U	[deduced] The type of the data member.

Parameters

[in]

memberVariable

The address of the data member.

Returns

The AttributeAccessor.

Definition at line 81 of file object-vector.h.

References bianchi11ax::k, and NS_ASSERT.

Referenced by ns3::Ipv6ExtensionRoutingDemux::GetTypeId(), ns3::Ipv6L3Protocol::GetTypeId(), ns3::BuildingListPriv::GetTypeId(), AttributeObjectTest::GetTypeId(), ns3::tests::ConfigTestObject::GetTypeId(), ns3::ArpL3Protocol::GetTypeId(), ns3::Ipv4L3Protocol::GetTypeId(), ns3::Ipv6ExtensionDemux::GetTypeId(), ns3::Ipv6OptionDemux::GetTypeId(), ns3::TcpL4Protocol::GetTypeId(), ns3::UdpL4Protocol::GetTypeId(), ns3::ChannelListPriv::GetTypeId(), ns3::NodeListPriv::GetTypeId(), ns3::Node::GetTypeId(), ns3::QKDControl::GetTypeId(), ns3::QueueDisc::GetTypeId(), and ns3::WaveNetDevice::GetTypeId().

Here is the caller graph for this function:

MakeObjectVectorChecker()

template<typename T >

ns3::Ptr< const ns3::AttributeChecker > ns3::MakeObjectVectorChecker

(

void

)

Returns

The AttributeChecker.

See also

AttributeChecker

Definition at line 121 of file object-vector.h.
